KEY2
KEY1
P1-7. KEY1/KEY2
Panel key is detected.
When the A/D conversion value of the panel key becomes out of the specified range, normal operation will not
be available.
In that case, check the constant of voltage dividing resistor, solder condition, etc. Refer to table.
* When “P1-7. KEY1/KEY2” menu is selected, keys become non-operable due to detection of the values of all
keys. However, it is possible to advance to the next sub-menu by pressing the “SCENE RADIO” (forward)
key or “SCENE CD” (reverse) key on the remote control.
(Reference voltage: 3.3 V=255)
P1-7
KY:255/255
Display KEY2
0 – 11
PURE
DIRECT
12 – 32
TUNING
>>
33 – 54
TUNING
<<
55 – 77 AM
78 – 99 FM
100 – 121
PRESET
>
122 – 144
PRESET
<
145 – 166 MEMORY
167 – 186 INFO
187 – 205 STRAIGHT
206 – 226
PROGRAM
>
227 – 246
PROGRAM
<
255 Key off
Display KEY1
0 – 11
RADIO
(SCENE4)
12 – 32
CD
(SCENE3)
33 – 54
TV
(SCENE2)
55 – 75
BD/DVD
(SCENE1)
76 – 96
ZONE2
CONTROL
97 – 119
ZONE2
ON/OFF
120 – 142
INPUT
>
143 – 172
INPUT
<
173 – 202
MAIN ZONE
203 – 235
TONE
CONTROL
255 Key off
63
RX-V671/HTR-6064/RX-A710
