Yamaha RX-A710BL - Connecting the external devices; Connecting AV Sources and TV

En 5
4 Connecting the external devices
ZONE 2 ZONE CONTROL INFO MEMORY
FM AM
PURE DIRECT
VOLUME
VIDEOHDMI IN L AUDIO R
VIDEO AUX
STRAIGHTTONE CONTROL
BD/DVD TV CD RADIO
YPAO MIC USB PHONES
SILENT CINEMA iPod/iPhone
PROGRAM
SCENE
INPUT
MAIN ZONE
NATURAL SOUND AV RECEIVER RX-A710
PRESET CATEGORY TUNING/CH
AC IN
SPEAKERS
SURROUND BACK/ BI–AMP ZONE 2/PRESENCE
EXTRA SP
RRLL
COMPONENT
VIDEO
VIDEO
TRIGGER OUT
DOCK NETWORK
FMAM
75Ω
ANTENNA
P
R
P B
Y
P
R
P B
Y
AUDIO 2AUDIO 1
AV 6AV 5AV 4AV 3
(
CD
)(
TV
)
VIDEO
AV 2
AV 1
COAXIAL OPTICALCOAXIALOPTICAL
AV
OUT
COMPONENT
VIDEO
R
L
HDMI OUT
ARC
HDMI 1
(BD/DVD)
HDMI 2 HDMI 3 HDMI 4 HDMI 5
MONITOR OUT
IN
OUT
REMOTE
ZONE 2
OUT
SUBWOOFER
AUDIO
OUT
FRONT CENTER SURROUND
RL R L
SINGLE
SIRIUS
+12V
0.1A MAX.
HDMIOPTICAL
HDMI
HDMI
HDMI 1
(BD/DVD)
HDMI
HDMI
a
c
O
(
TV
)
OPTICAL
O
AV 4
HDMI OUT
ARC
HDMI
b
d
Audio out
(optical)
TV
HDMI in HDMI out
BD/DVD player
HDMI1 jackHDMI OUT jack
AV4 (OPTICAL) jack
Turn on this unit
This unit (rear)
This unit (front)
To an AC
wall outlet
1
Connect the external devices to this unit.
a Connect the BD/DVD player and this unit with an
HDMI cable.
If the BD/DVD player is currently connected to the
TV directly with an HDMI cable, disconnect the
cable from the TV and connect it to this unit.
b Connect the TV and this unit with another HDMI
cable.
c Connect the TV and this unit with a digital optical
cable.
This connection is required to play back TV audio
on this unit. If your TV supports ARC (Audio Return
Channel), this connection is unnecessary.
d Connect the supplied power cable to this unit and
then to an AC wall outlet.
• For information on how to connect radio antennas or other
external devices, see “SETUP” in “Owner’s Manual”.
2
Turn on this unit, TV and BD/DVD player.
3
With the remote control of the TV, switch
the TV input to display the video from this
unit.
The connections are complete. Move to the next
page to optimize the speaker settings.
