Connections
Caution: Plug the power cables for the subwoofer and other audio/video components into an AC out-
let only after you complete all other connections.
Basic connection example
To AC outlet
Center speaker
Surround back speaker
(in NS-P246 systems)
Subwoofer
Amplifier
Front speakers Surround speakers
Right RightLeft Left
Note: The rear panel of
various amplifiers may
differ in appearance.
