55
English
ADDITIONAL
INFORMATION
SPECIFICATIONS
FM SECTION
• Tuning Range
[U.S.A. and Canada models] ............................ 87.5 to 107.9 MHz
[Other models] .............................................. 87.50 to 108.00 MHz
• 50 dB Quieting Sensitivity (IHF, 100% mod.)
Mono/Stereo ........................ 2.0 µV (17.3 dBf) /25 µV (39.2 dBf)
• Selectivity (400 kHz) ............................................................... 70 dB
• Signal to Noise Ratio (IHF)
Mono/Stereo .............................................................. 76 dB/70 dB
• Harmonic Distortion (1 kHz)
Mono/Stereo ................................................................. 0.2%/0.3%
• Stereo Separation (1 kHz) ....................................................... 42 dB
• Frequency Response ........................... 20 Hz to 15 kHz +0.5, –2 dB
AM SECTION
• Tuning Range ......................................... 530/531 to 1710/1611 kHz
• Usable Sensitivity ............................................................. 300 µV/m
GENERAL
• Power Supply
[U.S.A. and Canada models] ............................... AC 120 V/60 Hz
[Australia model] ................................................. AC 240 V/50 Hz
[U.K., Europe and Singapore models] ................ AC 230 V/50 Hz
[Korea model] ...................................................... AC 220 V/60 Hz
[China model] ...................................................... AC 220 V/50 Hz
[General model] .................... AC 110-120 V/220-240 V, 50/60 Hz
• Power Consumption
[U.S.A. and Canada models] .................................. 210 W/280 VA
[Other models] ..................................................................... 210 W
Standby Mode ........................................................... 0.8 W or less
• Dimension (W x H x D) ................................... 435 x 151 x 322 mm
(17-1/8” x 5-15/16” x 12-11/16”)
• Weight ................................................................. 8 kg (17 lbs 10 oz)
*Specifications are subject to change without notice.
AUDIO SECTION
• Minimum RMS Output Power for Main, Center, Rear
1 kHz, 0.1% THD, 6 Ω
[U.S.A. and Canada models] ................................................. 70 W
[Other models] ....................................................................... 60 W
1 kHz, 0.7% THD, 6 Ω
[U.S.A. and Canada models] ................................................. 75 W
[U.K., Europe, Australia and Korea models] ......................... 65 W
• DIN Standard Output Power
[Europe model]
1 kHz, 0.7% THD, 4 Ω .......................................................... 75 W
• Maximum Power (EIAJ)
[China, Korea and General models]
1 kHz, 10% THD, 6 Ω ........................................................... 80 W
• Dynamic Power (IHF, 6/4/2 Ω)
[U.S.A. and Canada models] ................................... 85/100/115 W
[Other models] ........................................................... 75/95/105 W
• Frequency Response
CD, etc. to Main L/R .............................. 10 Hz to 100 kHz, –3 dB
• Total Harmonic Distortion
1 kHz, 30 W, 6 Ω, Main L/R ................................................. 0.06%
• Signal to Noise Ratio (IHF-A Network)
CD (250 mV, shorted) to Main L/R, Effect Off .............. h100 dB
• Residual Noise (IHF-A Network)
Main L/R ................................................................ 150 µV or less
• Channel Separation (1 kHz/10 kHz)
CD, etc. (5.1 kΩ terminated) to Main L/R ........ h60 dB/h45 dB
• Tone Control (Main L/R)
BASS Boost/Cut .................................................... ±10 dB/100 Hz
TREBLE Boost/Cut ............................................... ±10 dB/20 kHz
• Phones Output ........................................................... 300 mV/470 Ω
• Input Sensitivity
CD, etc. ................................................................... 150 mV/47 kΩ
6CH INPUT ............................................................ 150 mV/47 kΩ
• Output Level
OUT (REC) ........................................................... 150 mV/1.2 kΩ
OUTPUT SUBWOOFER ............................................. 4 V/1.2 kΩ
VIDEO SECTION
• Video Signal Type ...................................................... NTSC or PAL
• Composite Video Signal Level ...................................... 1 Vp-p/75 Ω
• Signal to Noise Ratio ........................................................... h50 dB
• Frequency Response (MONITOR OUT)
............................................................... 5 Hz to 10 MHz, –3 dB
11V340R_50-58_EN(3.2.27).p65 03.2.27, 6:28 PM55
