RX-V340/RX-V340RDS/
HTR-5630/HTR-5630RDS/DSP-AX340
RX-V340/RX-V340RDS/HTR-5630/HTR-5630RDS/DSP-AX340
36
0.1mV ~ 10.0mV
(DC)
R359 (MAIN Lch)
R360 (MAIN Rch)
R350 (CENTER)
R358 (REAR Lch)
R361 (REAR Rch)
■ CONFIRMATION OF IDLING CURRENT/アイドリング電流の確認
Confirmation of Idling Current of Main (1) P. C. B.
• Right after power is turned on, confirm that the voltage
across the terminals of R359 (Main Lch), R360 (Main
Rch), R350 (Center), R358 (Rear Lch), R361 (Rear
Rch) are between 0.1mV and 10.0mV.
メイン（1）基板のアイドリング電流の確認
注意：
Note:
Before the confirmation, remove the FUNCTION (4)
P.C.B. and connect the G651 of the FUNCTION (4) P.C.B.
to the chassis with a jumper wire or the like.
