RX-V350/HTR-5730
36
RX-V350/HTR-5730
No. Port No.
Function name
I/O Detail of function
44 P52 /ICCS O CS493x Reset (Unconnected)
45 P51 /CSPLD O Digital External Control IC CE (Unconnected)
For Flash Writing (HI)
CS-DSP INT/ABOOT (Unconnected)
Mute Surround
(Unconnected)
(Unconnected)
Clock Line for BD38xx System Control
Data Line for BD38xx System Control
µ-COM Power Supply, +5V
(Unconnected)
µ-COM Ground
(Unconnected)
(Unconnected)
(Unconnected)
Open (Unconnected)
(Unconnected)
(Unconnected)
PLL IC Enable/Destination Discriminate 1
PLL IC Clock/Destination Discriminate 0
Tuned
Tuner/ST
Tuner Mute
Protection Excess Current Detect
Power Limiter A
Open (Unconnected)
Connection Discriminate
Protection DC Detect
Temperature Detect
Open (Unconnected)
Key AD Input 0
Key AD Input 1
AD Ground
Protection Power Supply Voltage Detect
AD Reference
AD Power Supply
IC242: M30626FHPFP (MAIN P.C.B.)
16bit µ-COM (Main CPU)
Ohm 0.0 +1.0k +1.0k +1.5k +2.2k +3.3k +4.7k +6.8k +10.0k +22.0k +47.0k
V 0.0~0.3 ~0.65 ~1.05 ~1.55 ~2.05 ~2.65 ~3.15 ~3.6 ~1.0 ~4.4 ~4.75
ADKEY0 6CH INPUT INPUT INPUT INPUT PROGRAM PROGRAM
BASS/TREBLE BASS/TREBLE
STEREO CONTROL SPEAKERS
(94Pin,AN2)
><
MODE
><+ -
A/B/OFF
ADKEY1
TUNING MODE
MEMORY
PRESET/TUNING PRESET/TUNING
A/B/C/D/E FM/AM
PRESET/TUNING
PTY SEEK PTY SEEK EON
RDS MODE/FREQ
(95Pin,AN1)
> < MODE START
Key Input (A-D) Pull-Up Resistance 10 k-Ohms
To Next Page
