70 En
Customizing this unit (MANUAL SETUP)
Option menu 3 OPTION MENU
Use this menu to manually adjust the optional system parameters.
■ Signal information SIGNAL INFO
Use this feature to check audio and video signal information (see page 40).
Parameter Features Page
A)DISPLAY SET
Adjusts the brightness of the display and converts video signals.
81
B)MEMORY GUARD
Locks sound field program parameters and other “SET MENU” settings.
82
C)AUDIO SELECT
Designates the default audio input jack select setting for the input sources when you turn on
the power of this unit.
82
D)PARAM.INI
Initializes the parameters of a group of sound field programs.
82
E)ZONE 2 SET
Adjusts the Zone 2 parameters.
82
F)XM RADIO SET
Displays the current reception level of the XM Satellite Radio signals.
83
G)DOCK SET
Selects whether this unit charges the battery of the connected iPod or not when this unit is in
the standby mode.
83

Yamaha RX-V661 Specifications

General

Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Analog Audio Inputs	6
FM/AM Tuner	Yes
Dolby Digital	Yes
DTS	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Audio D/A Converter	192kHz/24-bit
Surround System Class	7.1 channel
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	17
HDMI Switching	Yes
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Tuner Bands	AM/FM
Preset Station Qty	40
Surround Sound	Yes
HDMI Version	1.2a
Digital Audio Inputs	4 Optical, 2 Coaxial
Additional Features	XM Ready
Video Inputs	Component
Video Outputs	Component
Audio Outputs	Headphones
Output Power / Channel	90 W
Width	17.1 in
Depth	16.75 inches
