How to fix a Yamaha Receiver remote control that is not working?
If your Yamaha Receiver's remote control isn't working, the batteries may be weak, or the internal microcomputer might have frozen. Try replacing the batteries with new ones and pressing the RESET button on the remote control.
What to do if learning cannot be made successfully on Yamaha RX-V692?
If learning is unsuccessful with your Yamaha Receiver (TRANSMIT/LEARN indicator doesn't light up or flash), it could be due to several reasons: * Weak batteries in either remote. Replace them and press the RESET button. * Improper distance between the remotes. Adjust the distance. * Incompatible signal coding or modulation: learning is not possible in this case. * Full memory capacity: delete unnecessary commands. * Frozen microcomputer: Press the RESET button on the remote.
Guidelines for replacing critical components and performing leakage current tests.
Advisory regarding lead solder and potential chemical hazards in components.
Diagram illustrating the front panel controls for the RX-V692 model.
Diagram illustrating the front panel controls for the RX-V692RDS model.
Diagrams showing rear panel connections for different regional models.
Detailed technical specs for audio output power, sensitivity, and distortion.
Technical specs for FM tuning range, sensitivity, and signal-to-noise ratio.
Technical specs for AM tuning range, sensitivity, and signal-to-noise ratio.
Technical specs for video signal types, levels, and frequency response.
General details including power supply, consumption, weight, and accessories.
Physical measurements (width, height, depth) of the AV receiver.
Diagram showing the locations of major internal circuit boards.
Step-by-step guide for safely removing the top cover, bottom cover, and front panel.
Explains the function, initiation, and cancellation of the diagnostic mode.
Details the diagnostic menus and sub-menus available for testing.
Information on how the FL display shows diagnostic mode status and messages.
Specific procedures for Main Bypass, Front RAM Through, and Main DSP Through diagnostics.
Procedures for Effect, Manual Test, Pro Logic, and Factory Preset diagnostics.
Procedure for the AD Data Check diagnostic test.
List of necessary test equipment for accurate tuner calibration.
Detailed steps for performing discriminator balance, distortion, and sensitivity adjustments.
Detailed steps for performing AM sensitivity and auto-tuning adjustments.
Method for checking and adjusting the amplifier's idling current.
Detailed pin configuration and functional description of the main system controller IC.
Pinout and functional description for the LC74781-9626 Superimpose IC.
Pinout details and functions for various other integrated circuits.
Pin number assignments for the display unit.
Assignments for display grid and anode segments.
Illustration of the tuner circuit board's foil side with component placement.
Foil side layout diagrams for various input circuit boards.
Foil side layout diagrams for the unit's operation circuit boards.
Foil side layout diagrams for the amplifier circuit boards.
Foil side layout diagrams for amplifier PCBs (continued).
High-level functional overview of the AV receiver's architecture.
Detailed block diagram illustrating the tuner circuitry.
Visual representations of pin connections for various electronic components.
Detailed circuit diagram for the tuner section, including all components.
Detailed circuit diagram for the input signal processing stages.
Detailed circuit diagrams for operation and buffer sections.
Detailed circuit diagrams for the main amplifier power stages.
Detailed circuit diagrams for amplifier stages (continued).
Key to abbreviations used for electrical components in the parts list.
List of components used on the tuner printed circuit board.
List of components for the amplifier PCBs.
Component lists for amplifier PCBs (continued).
Component lists for amplifier PCBs (continued).
Component lists for the operation PCBs.
Component lists for operation PCBs (continued).
Component lists for operation and input PCBs.
Component lists for the input PCBs.
Component lists for input PCBs (continued).
Component lists for input and buffer PCBs.
Specific part numbers for carbon resistors by value and wattage.
Illustrated breakdown of the unit's components by model type.
List of mechanical parts, their part numbers, and descriptions.
Circuit diagram for the remote control transmitter.
Fixed codes for macro transmission and button functions.
To Next Page
General
