EAU11882
Tachometer
The tachometer allows the rider to
monitor the engine speed and keep it
within the ideal power range.
NOTICE
ECA10032
Do not operate the engine in the ta-
chometer red zone.
Red zone: 7000 r/min and above
EAU1234H
Handlebar switches
Left
Left
Right
1. Tachometer
2. Tachometer red zone
1
2
1. Dimmer switch “ / ”
2. Pass switch “ ”
1. Turn signal switch “ / ”
2. Horn switch “ ”
1. Engine stop switch “ / ”
2. Hazard switch “ / ”
1
2
1
2
1
2
