Specifications
29 En
ADDITIONAL
INFORMATION
AUDIO SECTION
• Output Level/Impedance (fixed)
DAB (0 dB, Full) ...................................................... 2.0 V/1.2 kΩ
FM (40 kHz Dev., 1kHz) .......................................... 1.0 V/1.2 kΩ
AM (30% mod., 1 kHz) .......................................... 0.36 V/1.2 kΩ
DAB SECTION
• Tuning Range
(Band III) ............................................................ 174 to 240 MHz
(L-Band) ......................................................... 1452 to 1492 MHz
• Sensitivity
(Band III) ........................................................................ –98 dBm
(L-Band) ......................................................................... –93 dBm
• Selectivity (for adjacent channel)
(Band III) ............................................................................. 40 dB
(L-Band) .............................................................................. 40 dB
• Signal to Noise Ratio .............................................................. 95 dB
• Total Harmonic Distortion ..................................................... 0.01%
• Stereo Separation (1 kHz) ........................................................ 85dB
• Frequency Response .................. 20 Hz to 20 kHz, +0.5 dB/–1.0 dB
• Antenna Input (unbalanced) ..................................................... 50 Ω
FM SECTION
• Tuning Range ................................................. 87.50 to 108.00 MHz
• 50 dB Quieting Sensitivity (IHF, 100% mod.)
Mono .................................................................... 3 µV (20.2 dBf)
• Usable Sensitivity (Signal to Noise 30 dB)
Mono ...................................................................................... 1 µV
Image Response Ratio ......................................................... 80 dB
IF Response Ratio ................................................................ 70 dB
Selectivity (400 kHz) ........................................................... 70 dB
• Signal to Noise Ratio (IHF)
Mono/Stereo ............................................................. 80 dB/75 dB
• Harmonic Distortion (1 kHz)
Mono/Stereo ................................................................ 0.3%/0.5%
• Stereo Separation (40 kHz Dev.)
1 kHz .................................................................................... 43 dB
• Frequency response (20 Hz to 15 kHz) ................................... –3 dB
• Antenna Input (unbalanced) ..................................................... 75 Ω
AM SECTION
• Tuning Range ......................................................... 522 to 1620 kHz
• Usable Sensitivity ............................................................. 300 µV/m
• Selectivity ............................................................................... 30 dB
• Signal to Noise Ratio .............................................................. 50 dB
• Image Response Ratio ............................................................ 35 dB
• Harmonic Distortion ................................................................ 1.0%
GENERAL
• Power Supply ........................................................ AC 230 V, 50 Hz
• Power Consumption .................................................................. 9 W
• Dimensions (W x H x D) .................................. 435 x 87 x 307 mm
• Weight .................................................................................... 3.2 kg
* Specifications are subject to change without notice.
