Yamaha UD-Stomp - Page 37

UD-Stomp
8
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK: Japan only
*
*
Circuit Board PN1/2 (V838980)(X2180B0)
Circuit Board PN2/2 (V838980)(X2180B0)
Spacer 8
LED Holder LED3-1A 4
Connector Assembly C& #24 2P L60 (V654510) 4
Push Switch ADS-003-A10 1(SELECT),2(ON/OFF), 4 05
3(TAP TEMPO),
BYPASS/BANK/TAP TEMPO
C0301 Ceramic Capacitor (Chip) 0.1000 25V Z 01
-0315 Ceramic Capacitor (Chip) 0.1000 25V Z 01
CN301 Connector Base Post M2426XXR 6P SE 01
CN302 Connector Base Post M2426XXR 9P SE 01
CN303 Connector Base Post M2426XXR 11P SE
CN304 Connector Base Post M2426XXR 12P SE 01
CN305 Connector Base Post M2426XXR 14P SE 01
CN306 Connector Base Post M2426XX 14P TE
CN307 Connector Base Post M2426XX 2P TE 01
-310 Connector Base Post M2426XX 2P TE 01
D0301 Diode 1SS355 TE-17 01
-0321 Diode 1SS355 TE-17 01
IC301 IC 74HC374DT D-FF 02
-307 IC 74HC374DT D-FF 02
IC308 IC 74HC4052DT MULTIPLEXER 02
IC309 IC 74HC4052DT MULTIPLEXER 02
LD301 LED Display LTC-5836E GROUP/BANK/PATCH 05
LD302 LED LT311G-41-C13 RE 1 01
LD303 LED LT311G-41-C13 RE 2 01
LD304 LED LT311G-41-C13 RE 3 01
LD305 LED LT311G-41-C13 RE BANK 01
L0301 Chip Inductance BLM21B751S 2125 03
-0309 Chip Inductance BLM21B751S 2125 03
R0301 Carbon Resistor (chip) 1.0K 0.1 J
R0302 Carbon Resistor (chip) 1.0K 0.1 J
-0304 Carbon Resistor (chip) 1.0K 0.1 J
R0305 Carbon Resistor (chip) 560 0.1 J
-0321 Carbon Resistor (chip) 560 0.1 J
R0322 Carbon Resistor (chip) 820 0.1 J
-0345 Carbon Resistor (chip) 820 0.1 J
R0346 Carbon Resistor (chip) 10K 0.1 J
-0362 Carbon Resistor (chip) 10K 0.1 J
R0363 Carbon Resistor (chip) 560 0.1 J
-0366 Carbon Resistor (chip) 560 0.1 J
SW301 Push Switch SKHQFN GREEN UP 02
SW302 Push Switch SKHQFN GREEN DOWN 02
SW303 Push Switch SKHQFN GREEN UTILITY 02
SW304 Push Switch SKHQFN GREEN STORE 02
SW305 Push Switch SKHQFN GREEN EFFECT BAND 1 02
SW306 Push Switch SKHQFN GREEN EFFECT BAND 2 02
SW307 Push Switch SKHQFN GREEN EFFECT BAND 3 02
SW308 Push Switch SKHQFN GREEN EFFECT BAND 4 02
SW309 Push Switch SKHQFN GREEN EFFECT BAND 5 02
SW310 Push Switch SKHQFN GREEN EFFECT BAND 6 02
SW311 Push Switch SKHQFN GREEN EFFECT BAND 7 02
SW312 Push Switch SKHQFN GREEN EFFECT BAND 8 02
SW313 Push Switch SKHQFN GREEN CONNECT 02
SW314 Push Switch SKHQFN GREEN GROUP 02
SW315 Push Switch SKHQFN GREEN SYNC 02
SW316 Push Switch SKHQFN GREEN WAVE 02
SW317 Push Switch SKHQFN GREEN FUNCTION 02
VR301 Rotary Variable Resistor RK09L1140 10KB ASSIGNABLE CONTROL 03
VR302 Rotary Variable Resistor RK09L1140 10KB COARSE 03
VR303 Rotary Variable Resistor RK09L1140 10KB FINE 03
VR304 Rotary Variable Resistor RK09L1140 10KB LOW CUT 03
VR305 Rotary Variable Resistor RK09L1140 10KB HIGH CUT 03
VR306 Rotary Variable Resistor RK09L1140 10KB FEEDBACK 03
VR307 Rotary Variable Resistor RK09L1140 10KB DIRECT LEVEL 03
VR308 Rotary Variable Resistor RK09L1140 10KB TAP 03
VR309 Rotary Variable Resistor RK09L1140 10KB SPEED 03
VR310 Rotary Variable Resistor RK09L1140 10KB DEPTH 03
AAX33470
AAX33480
V6220800
V6624600
--
V6124500
UX145100
UX145100
VV068000
VV068300
VV068500
VV068600
VV068800
VV067400
VV066200
VV066200
VT332900
VT332900
XZ102A00
XZ102A00
XZ101A00
XZ101A00
V5801000
VV620800
VV620800
VV620800
VV620800
VS740100
VS740100
RG006100
RG006100
RG006100
RG005560
RG005560
RG005820
RG005820
RG007100
RG007100
RG005560
RG005560
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
VK701100
V5264800
V5264800
V5264800
V5264800
V5264800
V5264800
V5264800
V5264800
V5264800
V5264800
