Yamaha VX110 Sport User Manual

8-10
E
HULL
HOOD
FRONT HOOD
SERVICE POINTS
Rivet Installation
1. Install:
• Rivets
Installing steps:
• Insert a rivet completely in the holes in
both the storage compartment panel
1
and inner hull.
• Push in the rivet pin
2
until it clicks and
is flush with the top of the rivet.
NOTE:
• To remove a rivet, push the rivet pin in
until it clicks and is below the top of the
rivet.
• Before reinstalling a rivet, hold the rivet
flange
a
with both hands and push the
rivet pin perpendicularly against a hard
flat surface until the pin protrudes from the
top of the rivet.
2
1
a

Yamaha VX110 Sport Specifications

General

Displacement	1052cc
Type	Personal Watercraft
Width	46.1 inches
Seating Capacity	2
Engine Type	4-stroke, 4-cylinder
