Yamaha VX110 Sport User Manual

E
A50001-1-4
SYMBOLS
Symbols 1 to 9 are designed to indicate the
content of a chapter.
1
General Information
2
Specifications
3
Periodic Inspection and Adjustment
4
Fuel System
5
Power Unit
6
Jet Pump Unit
7
Electrical System
8
Hull and Hood
9
Trouble Analysis
Symbols 0 to E indicate specific data.
0
Special service tool
A
Specified oil or fluid
B
Specified engine speed
C
Specified tightening torque
D
Specified measurement
E
Specified electrical value
(resistance, voltage, electric current)
Symbols F to I in an exploded diagram indi-
cate the grade of lubricant and the lubrication
point.
F
Apply Yamaha 4-stroke motor oil
G
Apply water resistant grease
(Yamaha grease A, Yamaha marine grease)
H
Apply ThreeBond 1104J or ThreeBond 1280B
I
Apply molybdenum disulfide grease
Symbols J to N in an exploded diagram indi-
cate the type of sealant or locking agent and
the application point.
J
Apply Gasket Maker
K
Apply LOCTITE 271 (red)
L
Apply LOCTITE 242 (blue)
M
Apply LOCTITE 572
N
Apply silicone sealant
NOTE:
Additional symbols may be used in this man-
ual.
12
34
56
78
90
AB
CD
EF
GH
IJ
KL
MN
GEN
INFO
SPEC
INSP
ADJ
FUEL
POWR
JET
PUMP
–+
ELEC
HULL
HOOD
TRBL
ANLS
T
R
.
.
E
A
1280B1104J
M
GM
271
LT
242
LT
572
LT
SS

Yamaha VX110 Sport Specifications

General

Displacement	1052cc
Type	Personal Watercraft
Width	46.1 inches
Seating Capacity	2
Engine Type	4-stroke, 4-cylinder
