9-14
9
7. Place an oil pan under the engine to col-
lect the used engine oil.
8. Remove the engine oil drain bolts and
their gaskets to drain the oil from the en-
gine.
9. Place an oil pan under the oil cooler drain
to collect the used engine oil.
10. Remove the oil cooler drain bolts and
their gaskets to drain the oil from the oil
cooler.
1. Trough
1
1. Engine oil drain bolt
2. Gasket
2
1
