WATER PUMP
6-8
EAS20066
WATER PUMP
Removing the water pump
Order Job/Parts to remove Q’ty Remarks
Coolant
Drain.
Refer to “CHANGING THE COOLANT” on
page 3-26.
1 Water pump inlet hose 1 Disconnect.
2 Water pump assembly 1
1
2
12 Nm (1.2 m • kgf, 8.7 ft • Ibf)
