Yamaha XSR 2016 - Page 45

CHASSIS SPECIFICATIONS
2-8
Brake disc runout limit (as measured on
wheel)
0.15 mm (0.0059 in)
Brake pad lining thickness 6.0 mm (0.24 in)
Limit 1.0 mm (0.04 in)
Master cylinder inside diameter 12.7 mm (0.50 in)
Caliper cylinder inside diameter 38.18 mm (1.50 in)
Specified brake fluid DOT 4
Front suspension
Type Telescopic fork
Spring Coil spring
Shock absorber Hydraulic damper
Front fork travel 137.0 mm (5.39 in)
Wheel travel 137 mm (5.4 in)
Fork spring free length 305.3 mm (12.02 in)
Limit 299.1 mm (11.78 in)
Inner tube bending limit 0.2 mm (0.01 in)
Recommended oil Yamaha Suspension Oil G10
Quantity (left) 444.0 cm³ (15.01 US oz, 15.66 Imp.oz)
Quantity (right) 431.0 cm³ (14.57 US oz, 15.20 Imp.oz)
Level (left) 174 mm (6.9 in)
Level (right) 175 mm (6.9 in)
Spring preload
Adjusting system Mechanical adjustable type
Unit for adjustment mm
Adjustment value (Soft) 19
Adjustment value (STD) 16
Adjustment value (Hard) 4
Rebound damping
Adjusting system Mechanical adjustable type
Unit for adjustment Click
Adjustment value from the start position
(Soft)
12
Adjustment value from the start position
(STD)
7
Adjustment value from the start position
(Hard)
1
Rear suspension
Type Swingarm (link suspension)
Spring Coil spring
Shock absorber Gas-hydraulic damper
Rear shock absorber assembly travel 60.0 mm (2.36 in)
Wheel travel 130 mm (5.1 in)
Spring preload
Adjusting system Mechanical adjustable type
Unit for adjustment Cam position
Adjustment value (Soft) 1
Adjustment value (STD) 4
Adjustment value (Hard) 7
Rebound damping
Adjusting system Mechanical adjustable type
Unit for adjustment Turn
