CABLE ROUTING
2-38
1. Throttle cable
2. Meter assembly
3. Meter assembly lead
4. Front turn signal light lead (left)
5. Headlight stay
6. Horn lead
7. Horn
8. Brake hose
9. Front turn signal light lead (right)
10.Wire harness
11.Main switch lead/Immobilizer unit lead
12.Handlebar switch lead (left)/Handlebar switch
lead (right)
13.Handlebar switch lead (right)
14.Handlebar switch lead (left)
15.Guide
A. Fasten the center of the metallic area of the
brake hose with the clamp. The opening in
the clamp should face downward then.
Fasten the protector area of the throttle
cables with the clamp (opening side).
B. Pass the meter lead in front of the throttle
cable.
C. Fasten the handlebar switch lead (left) to the
handlebar next to the clutch lever with the
plastic locking tie. The buckle of the plastic
locking tie should face toward the front upper
side and the end should face downward.
D. Install the clamp of the handlebar switch lead
(left) and handlebar switch lead (right) into
the guide holes.
E. Pass the front turn signal light lead (left), han-
dlebar switch lead (left) and handlebar switch
lead (right) through the holes on the left side
of the headlight body.
F. Pass the front turn signal light lead (right) and
wire harness through the holes on the right
side of the headlight body.
G. Pass the front turn signal light lead in front of
the brake hose.
H. Install the wire harness clamp into the long
hole on the guide.
I. Pass the main switch lead and immobilizer
unit lead on top of the guide.
J. Fasten the handlebar switch lead (right) to
the handlebar next to the brake master cylin-
der with the plastic locking tie. The buckle of
the plastic locking tie should face toward the
front upper side and the end should face
downward.
K. Pass the main switch lead, immobilizer unit
lead and throttle cables through the guide.
Pass the main switch lead and immobilizer
unit lead on the right side of the vehicle.
L. Handlebar front view
M. Fasten the handlebar switch lead to the lower
handlebar holder with the plastic locking tie.
The buckle of the plastic locking tie should
face the front and the end should face the
outside of the vehicle.
N. Vehicle forward direction
O. Install the clamp of the horn lead to the head-
light stay as shown in the illustration.
P. The terminals should face the outside of the
vehicle.
Q. Install the wire harness clamp into the hole
on the headlight stay.
To Next Page
