CABLE ROUTING
2-40
1. Handlebar switch coupler 2 (left)
2. Handlebar switch coupler 1 (left)
3. Turn signal light coupler (left)/Turn signal light
coupler (right)
4. Auxiliary light coupler
5. Handlebar switch coupler 1 (right)
6. Handlebar switch coupler 2 (right)
7. Coupler holder
A. Connect the handlebar switch coupler (left)
and install the wire harness side of the han-
dlebar switch coupler into the hole on the
coupler holder.
B. Headlight body left hole
C. Fasten the positioning tape area of the turn
signal light lead with the clamp and install the
clamp into the hole on the headlight body.
The end of the clamp should face the left
side.
D. After connecting the auxiliary light coupler,
install the wire harness side of the auxiliary
light coupler into the hole on the headlight
body.
E. Headlight body right side hole
F. Connect the handlebar switch coupler (right)
and install the wire harness side of the han-
dlebar switch coupler into the hole on the
coupler holder.
G. Pass the handlebar switch lead 1 (right), han-
dlebar switch lead 1 (left), handlebar switch
lead 2 (left), turn signal light lead (wire har-
ness side) on the inside of the guide. The
position of each lead does not matter.
H. Pass the handlebar switch lead 1 (right), han-
dlebar switch lead 2 (right), handlebar switch
lead 1 (left), turn signal light lead (wire har-
ness side) on the inside of the guide. The
position of each lead does not matter.
I. Pass the handlebar switch lead 1 (right), han-
dlebar switch lead 2 (right), handlebar switch
lead 2 (left), turn signal light lead (wire har-
ness side) on the inside of the guide. The
position of each lead does not matter.
J. When installing the coupler to the coupler
holder, install the handlebar switch coupler 2
(right) first followed by the handlebar switch
coupler 1 (right), handlebar switch coupler 1
(left) and handlebar switch coupler 2 (left).
K. Pass the handlebar switch lead 2 (right), han-
dlebar switch lead 1 (left), handlebar switch
lead 2 (left), turn signal light lead (wire har-
ness side) on the inside of the guide. The
position of each lead does not matter.
