- 8 -
SPEC
Rear brake
Brake type Leading, trailing - drum brake ----
Operation Right-foot operation ----
Brake pedal position 10 mm (0.39 in) ----
Brake drum
Inside diameter 110 mm (4.33 in) 111 mm
(4.37 in)
Lining thickness 4 mm (0.16 in) 1.5 mm
(0.06 in)
Shoe spring free length 50.5 mm (1.99 in) ----
Front suspension
Suspension type Telescopic fork ----
Front fork type Coil spring/oil damper ----
Front fork travel 225 mm (8.86 in) ----
Spring
Free length 594.7 mm (23.41 in) 582.8 mm
(22.94 in)
Spring rate (K1) 3.4 N/mm (0.34 kgf/mm, 19.4 lb/in) ----
Spring stroke (K1) 0 ~ 105 mm (0 ~ 4.13 in) ----
Spring rate (K2) 3.9 N/mm (0.39 kgf/mm, 22.27 lb/in) ----
Spring stroke (K2) 105 ~ 230 mm (4.13 ~ 9.06 in) ----
Optional spring available No ----
Standard enclosed gas/air pressure 2,000 kPa (20 kgf/cm
2
, 290 psi) ----
Fork oil ----
Recommended oil Fork oil 10 W or equivalent ----
Quantity (each front fork leg) 366 cm
3
(12.9 Imp oz, 12.4 US oz) ----
Level (from the top of the inner tube,
with the inner tube fully compressed,
and without the fork spring)
140 mm (5.51 in) ----
Steering
Steering bearing type Ball and taper roller bearing ----
No./size of steel balls (upper) 19 pcs./0.1875 in ----
Rear suspension
Suspension type Swingarm (link suspension) ----
Rear shock absorber assembly type Coil spring gas/oil damper ----
Rear shock absorber assembly travel 72 mm (2.83 in) ----
Spring
Installed length 174 mm (6.85 in) ----
Spring rate (K1) 60.3 N/mm (6.03 kgf/mm, 344.3 lb/in) ----
Spring stroke (K1) 0 ~ 87 mm (0 ~ 3.43 in) ----
Optional spring available No ----
Item Standard Limit
CHASSIS SPECIFICATIONS
