Yamaha XT250 2008 User Manual

PERIODIC MAINTENANCE AND ADJUSTMENT
7-18
1
2
3
4
5
6
7
8
9
2. Tap the tailpipe lightly, and then
use a wire brush to remove any
carbon deposits from the spark ar-
rester portion of the tailpipe and in-
side of the tailpipe housing.
3. Insert the tailpipe into the muffler,
and then install and tighten the
screw.
TIP
Make sure to align the screw hole when
inserting the tailpipe.
EAU21251
Carburetor
The carburetor is an important part of
the engine and its emission control sys-
tem, which requires very sophisticated
adjustment. Therefore, carburetor ad-
justments should be left to Yamaha
dealer, who has the necessary profes-
sional knowledge and experience.
1. Screw
1. Tailpipe
2. Spark arrester
1
1
2

Yamaha XT250 2008 Specifications

General

Compression Ratio	9.5:1
Ignition	CDI
Transmission	5-speed
Final Drive	Chain
Front Suspension	35mm telescopic fork; 8.9-in travel
Rear Suspension	Single shock; 7.1-in travel
Front Brake	Single disc, 245mm
Front Tire	2.75-21
Rear Tire	120/80-18
Wheelbase	53.5 in
Seat Height	31.9 in
Fuel Capacity	2.4 gal
Curb Weight	291 lb
Ground Clearance	11.2 in
Bore x Stroke	74.0mm x 58.0mm
Fuel System	Carburetor
Rear Brake	Drum
Length	84.6 inches
Engine Type	249cc, air-cooled, 4-stroke single; SOHC, 2 valves
