TIGHTENING TORQUES
Part to be tightened Thread size
Tightening torque
Nm m · kg ft · lb
Engine:
Spark plug M10 13 1.3 9.4
Engine oil drain bolt M35 32 3.2 23
Transmission oil drain bolt M14 23 2.3 17
Chassis:
Engine stay (front) and frame M8 33 3.3 24
Engine (front) and engine stay M10 42 4.2 30
Engine (rear-upper) and engine stay M10 42 4.2 30
Engine (rear-lower) and engine stay M10 42 4.2 30
Pivot shaft and frame M12 80 8.0 58
Swingarm and guard M8 23 2.3 17
Rear shock absorber and frame M10 45 4.5 32
Front arm and frame M10 32 3.2 23
Front shock absorber and front arm M10 45 4.5 32
Front shock absorber and frame M10 45 4.5 32
Tie-rod and steering column M10 25 2.5 18
Tie-rod and knuckle arm M10 25 2.5 18
Locknut (tie-rod) M10 30 3.0 22
Steering column and frame M10 30 3.0 22
Bracket (steering column) and frame M8 23 2.3 17
Steering column and handlebar holder M8 20 2.0 14
Front arm and steering knuckle M10 30 3.0 22
Front wheel hub and wheel M10 55 5.5 40
Front wheel hub and steering knuckle M14 70 7.0 50
Camshaft lever (front brake) and camshaft M6 9 0.9 6.5
Rear axle and ring nut M33 Refer to NOTE
Rear wheel hub and wheel M10 55 5.5 40
Rear wheel hub and rear axle M14 120 12.0 85
Swingarm (rear) and hub
Upper M12 85 8.5 61
Lower M10 60 6.0 43
Brake drum (rear brake) and boss M8 21 2.1 15
Driven sprocket and hub M10 62 6.2 45
Camshaft lever (rear brake) and camshaft M6 9 0.9 6.5
Locknut (drive chain slack adjuster) M8 16 1.6 11
Locknut (lock bolt) M8 16 1.6 11
Bracket (foot board) and frame M8 33 3.3 24
Fuel cock and fuel tank M6 5 0.5 3.6
Front bumper and frame M8 23 2.3 17
Rear bumper and frame M8 23 2.3 17
Tensioner (drive chain) and frame M8 20 2.0 14
