Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
106
5A)
• 1:1 Connection
• 1:n Connection
Signal name
RDB
SDB
SG
TERM
CA3-ADPCOM-01
CA3-ADPTRM-01
Display
Shield
RDA
SDA
SG
-
+
FG
150Ω ±5%
(more than
1/2W)
Terminal
resistance
150Ω ±5%
(more than
1/2W)
Terminal
resistance
Terminal block
Signal name
Controller
User-created cable
Signal name
RDB
SDB
SG
TERM
CA3-ADPCOM-01
CA3-ADPTRM-01
Display
Shield
RDA
SDA
SG
FG
Shield
SG
-
+
-
+
FG
150Ω ±5%
(more than
1/2W)
Terminal
resistance
Terminal block
Signal name
Controller
Terminal block
Signal name
Controller
150Ω ±5%
(more than
1/2W)
Terminal
resistance
User-created cable
