Yamatake DMC10 Series User Manual

Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
3
1 System Configuration
The following shows the system configuration where the External Device from Yamatake Corporation and the
Display are connected.
Series CPU Link I/F SIO Type
Setting
Example
Cable
Diagram
SDC10 C1005
Terminal block on
the controller
RS422/485
(2wire)
Setting
Example 1
(page 10)
Cable
Diagram 5
(page 105)
SDC15
C1503
C1506
Terminal block on
the controller
RS422/485
(2wire)
Setting
Example 2
(page 12)
Cable
Diagram 6
(page 114)
SDC20/21
C2003
C2005
C2010
C2104
C2107
C2109
Terminal block on
the controller
RS232C
Setting
Example 3
(page 14)
Cable
Diagram 1
(page 79)
C2002
C2004
C2009
C2103
C2106
C2108
Terminal block on
the controller
RS422/485
(4wire)
Setting
Example 4
(page 16)
Cable
Diagram 2
(page 81)
RS422/485
(2wire)
Setting
Example 5
(page 18)
Cable
Diagram 3
(page 87)
SDC25/26
C252
C262
Terminal block on
the controller
RS422/485
(2wire)
Setting
Example 6
(page 20)
Cable
Diagram 6
(page 114)
SDC30/31
C30040
C30041
C31045
C31446
C31546
Terminal block on
the controller
RS422/485
(4wire)
Setting
Example 7
(page 22)
Cable
Diagram 2
(page 81)
RS422/485
(2wire)
Setting
Example 8
(page 24)
Cable
Diagram 3
(page 87)
SDC35/36
C352
C354
C362
C364
Terminal block on
the controller
RS422/485
(2wire)
Setting
Example 9
(page 26)
Cable
Diagram 6
(page 114)
SDC40A
C40A3
Terminal block on
the controller
RS232C
Setting
Example 10
(page 28)
Cable
Diagram 1
(page 79)
C40A2
Terminal block on
the controller
RS422/485
(4wire)
Setting
Example 11
(page 30)
Cable
Diagram 2
(page 81)
RS422/485
(2wire)
Setting
Example 12
(page 32)
Cable
Diagram 3
(page 87)
