Yamatake SDC30 Series - Page 5

Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
5
DCP551 DCP5512
Terminal block on
the controller
RS232C
Setting
Example 23
(page 54)
Cable
Diagram 1
(page 79)
RS422/485
(4wire)
Setting
Example 24
(page 56)
Cable
Diagram 2
(page 81)
RS422/485
(2wire)
Setting
Example 25
(page 58)
Cable
Diagram 3
(page 87)
DCP552 DCP5522
Terminal block on
the controller
RS232C
Setting
Example 26
(page 60)
Cable
Diagram 1
(page 79)
RS422/485
(4wire)
Setting
Example 27
(page 62)
Cable
Diagram 2
(page 81)
RS422/485
(2wire)
Setting
Example 28
(page 64)
Cable
Diagram 3
(page 87)
CMC10B CMC10B
Communications
connector on the host
side
RS422/485
(4wire)
Setting
Example 32
(page 72)
Cable
Diagram 7
(page 123)
Series CPU Link I/F SIO Type
Setting
Example
Cable
Diagram
