Yamato DE410 - Replacement Parts Table

39
Replacement parts table
DE410
Symbol Part Name
Code №
Specifications
CT1,2,3,4 Current Transformer 2-17-001-0002 CTL-6-S-400
ELB Earth leakage breaker 2-06-008-0004 BJC3-15-3N AC200V
FM Fan motor 2-14-001-0018 MLH2075Z AC200V
H1,2,3 Heater DE42S-30010 AC200V 830W
DoorSW Door switch LT00035254 OMRON LAB1(recreation)
PCB1 PIO board 1-24-000-0024
PCB2 PLANAR board 1-24-000-0065
PCB3 Power board 1-24-000-0025 Type 1
PCB4 Independent overheat prevention 1-27-001-0008
ⅣLE
PCB5 Lack phase board 1-19-001-0001
SSR1,2 Solid-state relay LT00028423 SSR-01
SW Membrane keypad 1-01-320-0001 Type 4
Tf Transformer 2-18-000-0023 AC200V
TH Thermocouple 1-16-001-0049
K thermocouple
(double sensor)
X1,2 Relay 2-05-000-0028 JR1aF-TM-DC12V
X3 Electromagnetic Contact LT00034446 FC-0ST 1a 200V
X4 Electromagnetic Switch LT00034445 SW-03 1a 0.4KW
HEPA filter 9-03-001-0002 NS-90-H(Y)
Filter 9-01-001-0001
φ78×t5
Differential pressure gage 5-04-001-0004
0～500Pa
DE610
Symbol Part Name
Code №
Specifications
CT1,2,3,4 Current Transformer 2-17-001-0002 CTL-6-S-400
ELB Earth leakage breaker 2-06-008-0004 BJC3-15-3N AC200V
FM Fan motor 2-14-001-0018 MLH2075Z, AC200V
H1,2,3 Heater DE62S-30010 AC200V 1200W
DoorSW Door switch LT00035254 OMRON LAB1(recreation)
PCB1 PIO board 1-24-000-0024
PCB2 PLANAR board 1-24-000-0065
PCB3 Power board 1-24-000-0025 Type1
PCB4 Independent overheat prevention 1-27-001-0008
ⅣLE
PCB5 Lack phase board 1-19-001-0001
SSR1,2 Solid-state relay LT00028423 SSR-01
SW Membrane keypad 1-01-320-0001 Type 4
Tf Transformer 2-18-000-0023 AC200V
TH Thermocouple 1-16-001-0042
K thermocouple
(double sensor)
X1,2 Relay 2-05-000-0028 JR1aF-TM-DC12V
X3 Electromagnetic Contact LT00034446 FC-0ST 1a 200V
X4 Electromagnetic Switch LT00034445 SW-03 1a 0.4KW
HEPA filter 9-03-001-0001 NS-170-H(Y)
Filter 9-01-001-0001
φ78×t5
Differential pressure gage 5-04-001-0004
0～500Pa
