Specification
FO100/200/300/310/410
FO100 FO200 FO300 FO310 FO410
Operating temperature
range
100 to 1150℃
Temperature
adjustment accuracy
±2℃ (@1150℃)
Time required to reach
highest temperature
@LT:1150℃(@RT:850℃)
Approx.
60min.(40min.)
Approx.
60min.(40min.)
Approx.
70min.(50min.)
Approx.
70min.(50min.)
Approx.
70min.(50min.)
Temperature
control system
PID control by VS4 controller
Sensor R thermocouple (W sensor)
Temperature
setting system
Digital setting
Temperature
display system
Digital display
Functions for Operation
・Fixed temperature operation
・Timer operation (Auto stop, Auto start)
・Program operation
(Max 6patterns: 30steps×1pattern, 15steps×2patterns or 10steps×3patterns)
Additional function Lock function, Auto recovering after power failure, Calibration offset
Safety device
Earth leakage/circuit breaker, Thermal fuse, Overheating prevention device,
Self-diagnostic functions (Sensor error, Memory error, Heater disconnection, SSR
short circuit)
Iron chrome wire (Cantal AF)
Heater
1.0KW 1.5KW 2.0KW 2.0KW 2.2KW
Cooling fan Axial fan motor
Furnace unit Ceramic fiber
Operating ambient
temperature range
5 to 35℃
Internal dimensions
(W×D×H mm)
100×150×100 100×250×150 200×250×150 200×250×150 200×300×150
External dimensions
(W×D×H mm)
346×405×516 346×405×516 446×505×566 446×505×566 446×555×566
Internal capacity Approx. 1.5L Approx. 3.75L Approx. 7.5L Approx. 7.5L Approx. 9L
100V AC 200V AC single phase
Power supply
(50/60Hz)
11A 16A 21A 11A 12A
Power cord
3 wires
with plug
3 wires with rounded terminal
Weight Approx. 24Kg Approx. 30Kg Approx. 37Kg Approx. 37Kg Approx. 38Kg
Fuse
×1 ×1 ×1 ×1 ×1
Attached
accessories
Other Instruction manual
 The value for performance is under the ambient temperature of 23℃±5℃, the humidity of 65％RH±20％,
and without load.
 The projection is not included for external dimensions.
