Yanmar 4JH5E - 4 JH4-TE, 4 JH4-HTE1 and 4 JH4-HTE Marine Gear or Sail Drive

SPECIFICATIONS
106 JH Series Operation Manual
4JH4-TE, 4JH4-HTE1 and 4JH4-HTE Marine Gear or Sail Drive
Model ZF30M KM4A2 KMH4A ZF25A
SD60-4 (coupled
at boat builder)
Down Angle0°7°8°8° -
Type Mechanical wet
multiple disk clutch
Mechanical cone
clutch
Hydraulic wet
multiple disk clutch
Hydraulic wet
multiple disk clutch
Mechanical
multiple friction
disc clutch
Reduction Ratio
(forward /
reverse)
2.15 / 2.64
2.70 / 2.64
1.47 / 1.47
2.14 / 2.14
2.63 / 2.63
2.04 / 2.04
2.45 / 2.45
1.93 / 1.93
2.48 / 2.48
2.23 / 2.23
2.49 / 2.49
Propeller Speed
(forward /
reverse) (min
-1
)
*
1444 / 1176
1150 / 1176
2115 / 2113
1451 / 1450
1180 / 1179
1520 / 1520
1263 / 1263
1607 / 1607
1250 / 1250
1391 / 1391
1245 / 1245
Lubrication
System
Splash Centrifugal pump Trochoid pump Trochoid pump Oil bath
Lubrication Oil ATF API CD or higher SAE #20 or #30 ATF 15W-40
Lubricating Oil
Capacity (total)
1.1 L (1.2 qt) 3.3 L (3.5 qt) 2.0 L (2.1 qt) 1.8 L (1.9 qt) 2.8 L (3.0 qt)
Long Reach
(75mm):
3.0 L (3.2 qt)
Lubricating Oil
Capacity
(effective)
0.2 L (0.2 qt) 0.3 L (0.3 qt) 0.2 L (0.2 qt) - -
Cooling: System Seawater cooling -
Weight 27.5 kg (61 lb) 30 kg (66 lb) 31 kg (68 lb) 30 kg (66 lb) 45.1 kg (99.4 lb)
Long Reach
(75mm):
49.7 kg (109.6 lb)
* At continuous power engine speed 2907 min
-1
