FUEL SYSTEM
BY Service Manual
6-7
Specifications
Special Torque Chart
Component Tightening Torque
Lubricating Oil
Application (Thread
Portion and Seat
Surface)
Reference Page
Fuel Injector Retaining Nut 9 N·m (80 in.-lb)
Not Applied
Installation of Fuel
Injector on page 6-16
High-Pressure Fuel Regulator Retaining Nut 80 N·m (59 ft-lb)
Replacing
High-Pressure Fuel
Control Valve on
page 12-27
High-Pressure Fuel Sensor Retaining Nut 70 N·m (52 ft-lb)
Replacing
High-Pressure Fuel
Sensor on page 12-28
High-Pressure Pump
Sprocket Nut Access
Plug
M30 x 1.0 70 N·m (52 ft-lb)
Replacing
High-Pressure Fuel
Pump on page 6-20
M40 x 1.5 30 N·m (22 ft-lb)
High-Pressure Pump Drive Sprocket Nut 65 N·m (48 ft-lb)
High-Pressure Fuel Line Union Nut 23 N·m (204 in.-lb)
Removing and
Installing
High-Pressure Fuel
Lines on page 6-17
Return Fuel Banjo Bolt to Fuel Rail 25 N·m (221 in.-lb)
Removing and
Installing Fuel Rail on
page 6-27
