21
INSTALLATION
WARNING: Pull out mains plug before carrying out any work on the equipment and
use only original parts.
Before starting any cleaning task, it is important to inspect the area for objects
that could create a hazard. Remove any objects from the work area that could be
tripped over, such as toys or outdoor furniture. Ensure that all doors and windows
are closed tightly.
Attach hand cranks. (Fig. C)
Fix hand crank onto the hose reel.
Assemble gun holster and cord bracket. (Fig. D)
Assemble the gun holster onto pressure washer.
Connect the hose and spray gun.
Install the high pressure hose rmly onto the spray gun. (Fig. E)
1. Press and hold the button near the trigger.
2. Insert the high pressure into the spray gun.
Then install the tip lance and selected nozzle onto the spray gun. (Fig. F)
Assemble inlet adapter. (Fig. G)
Attach the inlet adapter to the machine’s water inlet. Hand tighten only.
Connect garden hose and inlet adapter. (Fig. H)
Attach a hose with a quick connect coupling (not included) to the high pressure washer.
Connect to water supply (Fig. I)
In keeping with current regulations a pressure washer must never be operated
from the drinking water mains supply without a controllable backow preventer. A
suitable backow preventer in conformity with EN 12729 type BA must be used.
Water that has passed through a backow preventer is classied as non-potable.
NOTE: A backow preventer is available from specialist retailers.
Attach garden hose to water supply and turn water valve on fully on position.
Connect socket. (Fig. J)
Insert the mains plug into the socket.
