17
INSTALLATION
Installing the handle
1. Attach the lower handle onto the unit by using one bolt and one hand tension knob on
each side. (Fig. C)
2. Install the upper handle onto the lower handle by using one bolt and one hand tension
knob on each side. (Fig. D)
Fitting the cable clip
Ensure that the cable clips supplied are used to x the cable to the lower handle. (Fig. E)
Installing the grass bag
1. Attach the grass bag to the frame by xing all plastic hooks. (Fig. F)
2. Lift the safety ap with one hand and hook in the grass bag. (Fig. G)
3. Release the ejector ap to secure the grass bag in position.
Setting the cutting height (Fig. H)
CAUTION! The blade can cause serious injury. Before adjusting the mower height, stop the
engine and wait for the mower blade to stop completely.
1. Pull the lever towards the wheel, then move it forward or backward to adjust the cutting
height.
2. Move it to any one of the 7 positions for the desired cutting height.
3. Return lever into securing plate.
NOTE! Never use the lowest cutting height for the rst cut of the season or in
drought conditions. Only about one third of the grass height should be cut.
From position 1 to position 7, the cutting height ranges from 25mm to 75mm.
