10
ASSEMBLY
WARNING
Always ensure that the lawn mower is switched off and the plug is
removed from the power source before making any adjustments or
performing maintenance tasks.
WARNING
Read and follow the assembly and adjustment instructions for your
lawn mower. All fasteners are in the parts bag. Do not discard any
parts or material until the unit is assembled.
When assembling the lawn mower, refer to the illustration on the front cover and the ones
below (Fig. 3 & Fig.4) to aid in the assembly.
1. Fit the upper handle, middle handle and lower handle together with the quick release
lock system. You can rotate the quick release lock to adjust its tightness. (Fig.3)
2. Hang the collection bag as shown. (Fig. 4)
Fig.3 Fig.4
