DESCRIPTION OF PRODUCT PARTS
Fig 1
DESCRIPTION OF PRODUCT PARTS
As shown in Fig 1
1. Engine-B&S 300
2. Cable clip
3. Hand tensioning knob
4. Start/stop lever
5. Top handle
6. Rope guide
7. Grass bag
8. Cutting height adjustment lever
9. Deck
Check the box content
As shown in Fig 2
Fig 2
A. Main mower deck (with upper handle)
B. Lower handle
C. Grass bag
D. Accessories
E. Manual
WARNING: If any parts are damaged or missing, do not operate this tool until
the missing parts are replaced. Failure to heed this warning could result in serious
personal injury.
NOTE! Always recycle the packaging in accordance with local recycling schemes.
WARNING: This item requires a two person lift to remove from the packaging.
Make sure that you have sufcient space to put the lawnmower down. Keep your
feet apart so that you have a stable position, bend at the knees and keep your
back straight.
1
2
3
4
8
9
7
6
5
A
C D E
B
X
X
X
2
2
4
