10 11
Install the grass bag
1. Attach the grass bag to the frame by xing all plastic hooks.(see Fig.6)
2. Lift the safety ap with one hand and hook in the grass bag. (see Fig.7)
3. Release the ejector ap to secure the grass bag in position.
Fig 6
Fig 7
ASSEMBLY
Setting the cutting height
CAUTION! The blade can cause serious injury. Before adjusting the mower height,
stop the engine and wait for the mower blade to stop completely.
1. Pull the lever towards the wheel, then move it forward or backward to adjust the cutting
height.
2. Move it to any one of the 7 positions for the desired cutting height. (see g 8)
3. Return lever into securing plate.
NOTE! Never use the lowest cutting height for the rst cut of the season or in drought
conditions. Only about one thirds of the grass height should be cut. (see Fig.8)
From position 1 to position 7. The cutting height range from 25mm to 75 mm.
Fig 8
ADJUSTMENT
25mm-75mm
