MAINTENANCE AND REPAIR INSTRUCTIONS
STORING A UNIT
1. Perform all the general maintenance recommended in
the Maintenance Section of your operator’s manual.
2. Clean the exterior of the engine, drive shaft
assembly, debris shield and stringhead.
4. After fuel is drained, start engine.
5. Run engine at idle until unit stops. This will purge the
carburetor of fuel.
6. Allow the engine to cool (approx. 5 minutes).
7. Using a spark plug wrench, remove the spark plug.
Failure to follow
these steps may
cause varnish to form in the carburetor; this
may result in difficulty when starting or
permanent damage following storage. This
may void your warranty
WARNING:
8. Pour 1 teaspoon of clean 2-cycle oil into the
combustion chamber. Pull the starter rope slowly
several times to coat internal components. Replace
the spark plug.
9. Store the unit in a cool, dry place away from any source
of ignition such as an oil burner, water heater, etc.
REMOVING A UNIT FROM STORAGE
1. Remove spark plug.
2. Pull starter rope briskly to clear excess oil from
combustion chamber.
3. Clean and gap spark plug or install a new spark plug
with proper gap.
4. Prepare unit for operation.
5. Fill fuel tank with proper fuel / oil mixture. Refer to
the Oil and Fuel Information section.
SPECIFICATIONS
ENGINE*
DRIVE SHAFT and CUTTING ATTACHMENT*
Engine Type.......................................................................................................................................... Air-Cooled, 2-Cycle
Displacement ........................................................................................................................................... 1.95 cu in. (32 cc)
Ignition Type.......................................................................................................................................................... Electronic
Spark Plug Gap ................................................................................................................................. 0.025 in. (0.635 mm.)
Lubrication................................................................................................................................................... Fuel/Oil Mixture
Fuel/Oil Ratio................................................................................................................................................................ 40:1
Carburetor..................................................................................................................................... Primer / Diaphragm Type
Drive.................................................................................................................................................................. Direct Driver
Fuel Tank Capacity............................................................................................................................. 23.3 fl.oz. (689.7 ml.)
Drive Shaft Length ....................................................................................................................................... 52 in. (132 cm)
Handle .................................................................................................................................................................... J Handle
Approximate Unit Weight (No fuel) .......................................................................................................... 11.2 lbs. (5.1 kg.)
Cutting Path Diameter............................................................................................................................. 17 in. (43.18 cm.)
*All specifications are based on the latest product information available at the time of printing. We reserve the right to
make changes at any time without notice.
