Step 10: Attach Ridge Caps
Part 2
C: Make sure the Ridge Cap Shorts are ush to the outside edge of the roof then attach each end of the Ridge
Cap to each Ridge Cap Short with two #8 x 3/4” Metal Screws per side. (g. 10.5, 10.6 and 10.7)
Hardware
4 x #8 x 3/4” Sheet Metal Screw
Ridge
Cap
Ridge
Cap
#8 x 3/4” Sheet
Metal Screw
Ridge
Cap Short
Fig. 10.5
Fig. 10.6
Fig. 10.7
x 2
Ridge
Cap Short
Flush
