11
8 x Wood Screw /Vis à bois
16 x Wood Screw /Vis à bois
Step 4 - Attach Frame stiles to box Étape 4 – Fixez les montants au bac
x 4
x 8
8 x Frame Stile / Montant
133
133
S1
S2
S1
A. Attach 4 Frame Stiles (133) ush
to the edge of Vertical Wall Assembly
(036) using 2 (S2) Wood Screws per
Frame Stile.
B. Secure the Inside Wall Assemblies
(017) to the Frame Stile (133) from the
inside using 4 (S1) wood screws.
Repeat for 2 assemblies
036
036
036
x 4
S2
Répétez pour les 2 assemblages
A. Fixez 4 (133) montants afeurant
le bord de (036) l’assemblage du mur
vertical avec 2(S2) vis à bois par
montant.
B. Fixez les (017) assemblages de
murs intérieurs aux (133) montants
avec 4 (S1) vis à bois.
Flush to corners x4
Afeure aux coins
