Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
Hardware Identification ( )
1pc.
- Post
Mount Set (8Pk)
(Y70829-109)
1pc.
45
Twist Bracket
RT Set (2pk)
(Y70829-192)
1pc. -
Roof to Post
Bracket Set (4pk)
(Y70829-070)
1pc.
45
Twist Bracket
LT Set (2pk)
(Y70829-191)
2pc.
1/4" Nut
(Y08490-200)
2pc.
- 50mm
Hook
(Y00418-050)
2pc.
Carriage Bolt
(Y07428-260)
2pc.
Peak Post
(Y01000-094)
1pc.
- Roof Peak Set
(Y70829-125)
2pc.
Contoured Washer
(Y05918-211)
2pc.
Peak Loop
(Y20018-003)
1pc.
- Weather Seal -
Ridge Clip (8Pk)
(Y70818-074)
2pc.
Spring Clip
(Y09490-001)
4pc.
- Short Panel Right
(Y01036-128)
4pc.
- Long Panel Left
(Y01036-127)
2pc. Long Beam Insert
- (Y00429-124)
1pc.
- Gazebo ID Plaque
(Y70800-104)
1pc.
- Corner Cap Set (4Pk)
(Y70836-103)
1pc.
- Roof Panel Set
(Y70836-138)
4pc.
- Short Panel Left
(Y01036-126)
4pc.
- Long Panel Right
(Y01036-129)
4pc.
Ridge Cap Long 81.5
(Y01036-131)
2pc.
- Middle Panel
(Y01036-130)
4pc.
Roof Peak Bracket
(Y00429-125)
4pc.
Roof Edge Left 72.2 - (Y01036-134)
8pc.
Ridge Clip 102.5 - (Y01036-133)
2pc.
Roof Edge Right 72.2 - (Y01036-135)
4pc.
Ridge Cap Short 25.2
(Y01036-132)
2pc.
Roof Edge Right 96.2 - (Y01036-136)
1pc.
Peak Cap Long
(Y01036-137)
1pc.
- Roof to Beam
Bracket Set (14Pk)
(Y70829-123)
1pc.
Tie Wrap Bracket (4Pk)
(Y70829-106)
1pc.
1/4" Eye Lag
(Y00218-001)
