Yardistry YM12732 - Page 9

9 support@yardistrystructures.com
Part Identification ( )
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
30 x 76.2 x 2336.8 mm (1-3/16" x 3" x 92")
2pc. (2205)
- Tie FSC
(Y50229-2205)
28.8 x 76.2 x 2156.9 mm (1-1/8" x 3" x 84-15/16")
2pc. (2208)
- Strap Short - Large Roof FSC
(Y50229-2208)
28.8 x 76.2 x 2596.6 mm (1-1/8" x 3" x 102-3/16")
2pc. (2207)
- Strap FSC
(Y50229-2207)
28.8 x 76.2 x 1601.3 mm (1-1/8" x 3" x 62-15-16")
2pc. (2210)
- Strap Right - Large Roof FSC
(Y50229-2210)
28.8 x 76.2 x 1553.3 mm (1-1/8" x 3" x 61-1/8")
2pc. (2209)
- Strap Short FSC
(Y50229-2209)
28.8 x 76.2 x 1601.3 mm (1-1/8" x 3" x 62-15-16")
2pc. (2211)
- Strap Left - Large Roof FSC
(Y50229-2211)
31.8 x 81.6 x 574.7 mm (1-1/4" x 3-3/8" x 22-5/8")
1pc. (463)
- Spacer Top FSC
(Y50229-463)
