Centered and ush to
bottom of rafters
Roof to Beam
Bracket
F11.1
F11.2
A: On the back of both Large Roof Rafter Assemblies, centered and ush to the bottom of (2212), (2213) and
both (2206)’s attach one Roof to Beam Bracket per board with one S10 in the bottom hole and one S34 in the top
hole per bracket. (F11.1 and F11.2)
Step 11: Attach Roof to Beam Brackets
Large Roof Rafter Assemblies
8 x #8 x 1” Pan Screw
8 x #12 x 1-1/4” Pan Screw
Back View
(2206)
(2213)
(2212)
Large Fascia
Beam Assembly
Large Fascia
Beam Assembly
S10
S34
S10
S34
8 x Roof to Beam Bracket
