Step 10: Large Roof Rafter Assembly
Part 4
2 x (2214) Strap Brace
J: Turn Large Roof Rafter Assembly over then attach one (2214) to (2211) and (2210) with eight S11. Edges
should be ush. (F10.8 and F10.9)
K: Complete Steps F - J for both Large Roof Rafter Assemblies.
HardwareWood Parts
16 x #8 x 2” Wood Screw
Front View
Back View
F10.8
F10.9
Flush
(2211)
(2206)
(2210)
(2211)
(2210)
(2214)
S11
S11
