49 support@yardistrystructures.com
A: At each corner place one Corner Cap tight to Fascia Assemblies, push up so the bottom is tight to the bottom
of the assemblies then attach with four SM0 per Corner Cap. (F21.1 and F21.2)
HardwareComponents
4 x Corner Cap
Corner
Cap
Fascia
Assembly
F21.1
F21.2
Large
Fascia
Assembly
Tight
x 3
Step 21: Attach Corner and Beam Caps
SM0
SM0
16 x #8 x 3/4” Sheet Metal Screw
SM0
