51 support@yardistrystructures.com
Step 23: Secure Roof Peak Brackets
A: Tighten the six screws in Roof Peak Brackets then attach to Corner Rafters in the remaining holes with ten
S12. (F23.1)
Hardware
F23.1
Roof Peak
Bracket
Corner
Rafter
Roof Peak
Bracket
Corner
Rafter
Corner
Rafter
Corner
Rafter
x 10
S12
10 x #10 x 1-1/4” Pan Screw
S12
