Step 27: Metal Hooks and Plaque
Part 1
A: Two 50 mm Hooks are included with this unit for attaching wiring. They can be placed anywhere along the
Corner Rafters as needed. Pre-drill with a 1/8” drill bit before installing. (F27.1 and F27.2)
B: One Eye Lag is included with this unit for hanging items with a maximum weight of 22 lbs (10 kg). Pre-drill
with a 1/8” drill bit into center of (463) then install Eye Lag. (F27.1 and F27.3)
Hardware
2 x 50 mm Hooks
1 x Eye Lag
F27.1
F27.2
Corner
Rafter
50 mm Hook
Note: DO NOT ATTACH
ANY PRODUCT WHICH
WEIGHS GREATER
THAN 22 LBS (10 KG)
TO THE EYE LAG
Parts removed
for clarity
F27.3
(463)
(463)
Eye
Lag
Note: We have provided two
50 mm hooks for optional use
to hold in place any wires if
required. These hooks are
not designed to hold any
heavy products such as
lights, ower pots, etc.
Center
To Next Page
