Step 26: Twist Bracket Installation
A: Measure 3.75 in (9.53 cm) down from the inside of each post, place bottom of either 45° Twist Bracket LT or 45°
Twist Bracket RT at measured location then attach to post and Corner Rafter (Left or Right) with four S34 per bracket.
(F26.1 and F26.2)
45° Twist
Bracket
(LT/RT)
3.75 in
Corner Rafter
(Left or Right)
(9.53 cm)
Components
2 x 45° Twist Bracket LT
2 x 45° Twist Bracket RT
Hardware
16 x #12 x 1-1/4” Pan Screw
S34
S34
S34
F26.1
F26.2
