Yardistry YM12810X - Secure Roof to Beam Brackets; Reinforce Roof to Beam Brackets

39 support@yardistrystructures.com
A: From inside the assembly attach Roof to Beam Brackets to Beam Assemblies with two #12 x 1-1/2” Pan
Screws per bracket. (g. 17.1 and 17.2)
Hardware
24 x #12 x 1-1/2” Pan Screw
x 3
Step 17: Secure Roof to Beam Brackets
Inside View
Beam
Assembly
Fig. 17.1
Roof Panel
Assembly
Fig. 17.2
Roof to
Beam
Bracket
#12 x 1-1/2”
Pan Screw
Beam
Assembly
