Step 18: Secure Roof Peak Brackets
A: Tighten the two screws in Roof Peak Brackets then attach to Corner Rafters in the remaining holes with
fourteen #10 x 1-1/4” Pan Screws. (g. 18.1)
Hardware
14 x #10 x 1-1/4” Pan Screw
Fig. 18.1
Roof Peak
Bracket
Rafter
Corner
Roof Peak
Bracket
Rafter
Corner
Rafter
Corner
Rafter
Corner
#10 x 1-1/4”
Pan Screw x 14
