Yardistry YM12935 - Step 11: Attach Rafter Beam Brackets - Large Roof Rafter Assembly

31 support@yardistrystructures.com
4- Rafter to Beam Brackets
4-(1/4 T-nut, Lock nut)
8- 5/16 Large Flat Washer
4- 1/4 x 2” Hex Bolt
4- Rafter to Beam Brackets
4-(1/4 T-nut, Lock nut)
8- 5/16 Large Flat Washer
4- 1/4 x 2” Hex Bolt
F11.1
F11.2
A: On the Back of both Large Roof Rafter Assemblies place one Rafter Beam Bracket on (1086) Rafter Short
Right, (1087) Rafter Short Left and both (1088) Rafters. Loosely attach each bracket to rafters with one 1/4 x 2”
Hex Bolt (with two 1/4-5/16” large washers and one 1/4” lock nut). (F11.1 and F11.2)
Step 11: Attach Rafter Beam Brackets
- Large Roof Rafter Assembly
Back View
Hardware
Rafter Beam
Bracket
8 x 1/4 x 2” Hex Bolt
(1/4-5/16” large washer x 2, 1/4” lock nut)
(1088)
(1087)
(1086)
Components:
8 x Rafter Beam Bracket
1/4”
Lock
Nut
1/4 x 2”
Hex Bolt
1/4-5/16”
Large
Washer
1/4-5/16”
Large
Washer
