Yardistry YM12935 - Wood Deck Installation

7 support@yardistrystructures.com
Permanent Installation Examples cont.
Anchoring Hardware not included
Anchoring Hardware not included
Post Mounts have a 1.27 cm (1/2”) diameter hole
for anchoring hardware.
Concrete Patio [min. 3.705 m x 3.096 m (12’1-7/8” x 10’1-7/8”)]
with 15.24 cm (6”) clearance on all sides
Wood Deck [min. 3.705 m x 3.096 m (12’1-7/8” x 10’1-7/8”)]
with 15.24 cm (6”)clearance on all sides
Anchoring Hardware (not included)
Post Mount
