2247.9mm (88½")
Dimensions are approximate and are shown to assist in the identification of parts for
Part Identification ( )
assembly. Actual dimensions may be smaller or larger.
4pc. (1100) -
Post
Y70229-1100
926.9mm (36-1/2") 4pc. (740) -
Short Right Gusset
Y70229-740
Y50229-1078
4pc. (1078) -
Inside Short Beam
385.8mm (15-3/16")
Y50229-1090
8pc. (1090) -
Long Plinth
215.9mm (8½")
926.9mm (36-1/2") 4pc. (739) -
Short Left Gusset
Y70229-739
Y50229-1076
2pc. (1076) -
Left Outside Beam
1497mm (58-15/16")
Y50229-1077
2pc. (1077) -
Right Outside Beam
1497mm (58-15/16")
Y50229-1079
2pc. (1079) -
Inside Beam Long
2128.3mm (83-13/16")
Y50229-1089
8pc. (1089) - Plinth 190.5mm (7½")
Y50229-1093
2pc. (1093) -
Inside Beam
2235.2mm (88")
Y50229-1094
4pc. (1094) -
Inside End Beam 744.1
mm (29-5/16")
Y50229-1095
2pc. (1095) -
Right Outside Beam Long 1801.8
mm (70-15/16")
Y50229-1096
2pc. (1096) -
Left Outside Beam Long 1801.8
mm (70-15/16")
