Yardistry YM12952 - Page 12

12 support@yardistrystructures.com
( )
Dimensions are approximate and are shown to assist in the identication of
parts for assembly. Actual dimensions may be smaller or larger.
Hardware Identication
(Y01030-197)
4pc.
- Long Panel Right
1pc.
- Roof Panel Set
(Y70830-203)
4pc.
- Short Panel Left
(Y01030-200)
4pc.
- Long Panel Left
(Y01030-198)
8pc.
- Middle Panel
(Y01030-196)
4pc.
- Short Panel Right
(Y01030-199)
4pc.
Ridge Cap Long 81.5
(Y01030-131)
4pc.
Ridge Cap Short 25.2
(Y01030-132)
4pc.
Roof Edge Left 72.2 - (Y01030-134)
4pc.
Ridge Cap Middle - (Y01030-207)
8pc.
Ridge Clip 102.5 - (Y01030-133)
4pc.
Roof Edge Right 72.2 - (Y01030-135)
2pc.
- 50mm
Hook
(Y00418-050)
1pc.
- Weather Seal
Ridge Clip (8Pk)
(Y70818-074)
1pc.
- Weather Seal
Ridge Clip 75-1/2 (8Pk)
(Y70818-208)
1pc.
- Gazebo ID Plaque
(Y70800-104)
8pc.
Ridge Clip 73.5 - (Y01030-209)
2pc.
Ridge Edge Middle - (Y01030-210)
